Underground tanks

Underground tanks for detention, retention and storage.

North Island ENDURO, South Island XPRESS. Order standard sizes online, or send the plans and we'll quote the job.

1,000 to 30,000 litres Standard sizes priced online
Promax 3,000L ENDURO underground tank Promax 3,000L XPRESS underground tank
Built to AS/NZS 4766
North Island ENDURO, South Island XPRESS
Detention, retention and storage
Free to your nearest Mainfreight depot
Project pricing

Tell us about the job. We'll handle the spec.

What goes over the top, how wet the ground gets, where the outlet has to sit: all of it changes which tank is right. Send finished plans or a rough description of the job. A Promax specialist comes back with a tank and a price, plus the detail your drainlayer will need. Pricing several tanks or a whole subdivision? Send the tank schedule and we will quote the lot.

  • Send the volume from your consent, the plans or the full tank schedule
  • Tank, lid, riser and delivery priced together before you commit
  • Fast replies, usually within one business day
Promax has been making tanks in New Zealand since 1992.
The range

Which range is yours?

There are two underground ranges, and your island usually decides which one. Super Duty and TankGuard are heavier or outlet-protected builds within ENDURO. Pick a range and its sizes, prices and install detail are on that range's own page.

North Island
ENDURO

ENDURO

Rectangular, so the dig is a straight-sided trench rather than a round hole. Less excavation, less backfill. Built in the North Island.

Best for
Most North Island jobs
Depths
1.0 m, 575 mm low profile
Volumes
1,000 to 10,000 L
Priced online
14 standard sizes
See the ENDURO range
South Island
XPRESS

XPRESS

Cylindrical, in three diameters. On the 1.2 m the hole stays the same size whatever volume you pick, and only the length changes. Built in the South Island.

Best for
Most South Island jobs
Diameters
900 mm, 1.2 m and 1.9 m
Volumes
1,000 to 30,000 L
Priced online
10 standard sizes
See the XPRESS range
Super Duty

Super Duty

The ENDURO built heavier, for a high water table, rocky or heavy fill, or more load over the top.

1.0 m · 2,000 to 10,000 L · 9 sizes

See Super Duty
TankGuard

TankGuard

Outlet blockage protection for detention, so the tank keeps releasing at the rate the design calls for.

1.0 m · 2,000 to 10,000 L · On enquiry

See TankGuard

Every underground tank we make:

  • Built to AS/NZS 4766 for polyethylene storage
  • Detention, retention and wastewater storage
  • Multiple inlet and outlet plumbing ports
  • Trafficable with a steel lid and concrete surround
  • Installed to the Promax Installation Guide
  • Free to your nearest Mainfreight depot
Why Promax

The tank goes under. The site stays yours.

Sections are getting smaller and councils now want stormwater managed on site. An underground tank does both jobs at once: it sits under the yard, the driveway or the lawn without touching the building footprint or the landscaping. Promax has been making tanks in New Zealand since 1992, and a rep will spec the job with you before you order.

1992 the year Promax started making tanks in New Zealand
Zero space an underground tank takes up above ground
10 years pro-rata warranty on ENDURO underground tanks
No maintenance polyethylene does not rust, crack underground or need recoating
FAQ

Questions we get asked a lot

How does pricing work?

Standard sizes in both underground ranges are priced online, including GST: the twelve 1.0m ENDURO sizes, the 575mm low profile and the Super Duty builds in the North Island, and the nine 1.2m XPRESS sizes plus the 900mm compact in the South. Order online, or send us the job and we will confirm the tank, lid and delivery with you.

TankGuard and the 1.9m XPRESS are priced on enquiry. Pricing several tanks or a whole subdivision? Send the tank schedule and we will quote the lot.

How does delivery work?

Every underground tank travels free to your nearest Mainfreight depot, and you can collect from Promax instead if that suits the job. If you want the tank delivered to site, your Promax rep arranges it and quotes it with your order. ENDURO tanks of 6,000L and under are delivered free to site by hiab within the Auckland Metro area, and XPRESS tanks are delivered free to site inside the Christchurch Metro area.

What size do I need?

Your resource consent or stormwater engineer sets the volume, usually in litres or cubic metres.

If you have that number, go straight to the North Island ENDURO range or the South Island XPRESS range and pick the size. If you do not have it yet, send us what you do have and we will tell you what is needed to size it.

What's the difference between ENDURO and XPRESS?

Geography and shape, not budget. ENDURO is rectangular, built in the North Island, and runs 1,000 to 10,000 litres. XPRESS is cylindrical, built in the South Island, and runs 1,000 to 30,000 litres. Both cover detention, retention and storage.

The 1.2m and 900mm XPRESS are sold in the South Island. The 1.9m XPRESS is sold nationwide, with freight quoted with your order. For a North Island site, start with ENDURO.

Can I put it under the driveway?

Only with the right lid and riser. The standard polyethylene lid supplied with the tank is for garden areas. For a pedestrian or trafficable area the installation guide calls for a steel manhole lid and a Promax adjustable riser, which takes a concrete surround so vehicle loads are carried by the concrete and not the tank.

The guide has installation drawings for residential driveways (vehicles up to 2,500kg) and commercial driveways (vehicles up to 10,000kg). Anything heavier needs an engineer. Tell us what goes over the top and we will confirm the right lid and riser to order with the tank.

How close can it go to a house or retaining wall?

The installation guide sets a 45 degree line of influence that has to start at least 1,000mm from the edge of the house foundations, and at least twice the retaining height away from a retaining wall. Leave a minimum of 150mm between the tank and the excavation wall at the narrowest point. The design assumes the site meets the NZS 3604:2011 definition of good ground; if it does not, or the tank cannot sit outside those limits, a chartered professional engineer needs to look at the site.

What backfill does it need?

Washed crushed stone or gravel with angular particles no larger than 13.2mm, or clean naturally rounded gravel no larger than 19mm, with no more than 5% passing a 2.36mm sieve and a dry density of at least 1,500kg per cubic metre. Do not mix the approved backfill with sand or native soil, bring it up to at least the tank crown, place it in lifts of no more than 300mm, and probe it under the full length of the tank and into the ribs so there are no voids.

What documents can I get for the job?

The Underground Tank Installation Guide covers handling, location, excavation, backfill, anchoring and manholes, with installation drawings for lawn areas, residential driveways (vehicles up to 2,500kg) and commercial driveways (vehicles up to 10,000kg). The Underground Tank Riser Installation Guide is on the same downloads page, and the dimensions and weight of every size are on its product page.

What stops it floating in wet ground?

An empty tank in saturated ground wants to lift. Uplift restraint kits and installation anchors hold it down, and they are sized to the tank: one kit per 1,000 litres on the 1.0 m ENDURO and the 1.2 m XPRESS, so a 5,000 litre tank takes five, and one per 2,500 litres on the 1.9 m.

Stated burial depths in the installation guide assume dry ground with no hydraulic loads, so if groundwater is a known issue on your site, say so when you enquire and it goes into the spec.

When should I ask about Super Duty?

When the site has a high water table, rocky or heavy soil, flotation risk, or more load over the top than a standard install. It runs 2,000 to 10,000 litres, it is priced online as part of the North Island ENDURO range, and it is usually specified alongside an uplift restraint kit. Send your site details and we'll confirm whether it applies.

When is TankGuard relevant?

TankGuard suits stormwater detention projects where protecting the controlled discharge outlet from blockage is part of the design. It is built as a separate version of the tank rather than fitted afterwards, so ask us and we will quote the TankGuard version of the size you need.

What warranty do they carry?

Pro-rata, from the date of purchase, per the Promax Warranty Terms and Conditions:

  • ENDURO underground tanks: 10 years
  • Standard underground tanks: 5 years

The warranty covers the tank. Lids, fittings and inlet and outlet connections are excluded. The tank must be registered on promax.co.nz within 30 days of delivery.

Who installs it?

A drainlayer, working to the Promax Underground Tank Installation Guide that comes with the tank. Excavation, bedding and backfill all matter on an underground tank, and connecting into the drainage is restricted work in New Zealand, so it has to be done by a registered drainlayer.

What should I send you?

Your project location, the application, the required volume, site conditions, consent notes, and any plans or outlet specifications you have. Nothing needs to be finalised before you make contact.

Why does council require stormwater detention?

Most NZ councils now require new builds and infill developments to slow the stormwater leaving the site, particularly where roofs and driveways cover a large share of it. A detention tank meets that requirement: it sits empty, catches runoff in a storm, and releases it at the rate council allows. Your consent or engineer will state the volume. Send it through and we'll spec the tank.

What is a detention tank?

A detention tank holds stormwater during a storm and releases it gradually through a controlled outlet. It slows the rate of discharge from your site, which is commonly required by council.

What is a retention tank?

A retention tank stores rainwater or stormwater for later reuse: irrigation, toilet flushing or washdown, depending on the system design. The tank is the same one. What changes is the outlet arrangement and the fittings.

A dual-purpose tank does both in one unit. A 4,000 litre tank, for instance, can hold 1,850 litres of detention in the upper section and 2,150 litres of retention below it, so the council requirement and the water you reuse come out of a single install.

Still got questions? Talk to the team →
